CIP Objects Appendix A
Configuration Group 25
Group 25 contains configuration attributes from the Measurement Alarm
Object (0x396) Instances 13…19.
Configuration Group 26
Group 26 contains configuration attributes from the following objects:
• Measurement Alarm Object (0x396) Instances 20…24
• Voted Alarm Object (0x397) Instances 1 and 2
Table 106 - Configuration Group 25
Source Object Source Instance Source Attribute ID Name Data Type
0x396 13 18 Alarm Name SINT[32]
14 18 Alarm Name SINT[32]
15
18 Alarm Name SINT[32]
16 18 Alarm Name SINT[32]
17 18 Alarm Name SINT[32]
18
18 Alarm Name SINT[32]
19 18 Alarm Name SINT[32]
Table 107 - Configuration Group 26
Source Object Source Instance Source Attribute ID Name Data Type
0x396 20 18 Alarm Name SINT[32]
21 18 Alarm Name SINT[32]
22
18 Alarm Name SINT[32]
23 18 Alarm Name SINT[32]
24 18 Alarm Name SINT[32]
0x397 1
17 Voted Alarm 0 Name SINT[32]
2 17 Voted Alarm 1 Name SINT[32]
