518 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Object Specific Services
The Assembly Object provides no Object specific services.
Behavior
The contents of the input and output assemblies are configurable by way of an
Input and an Output member list that are a part of the device configuration
(Refer to Dynamix Configuration Manager Object
, Configuration Group 18).
These lists are not related to any Assembly Object services and so can neither
be defined nor viewed via this object.
Input Assembly
The input assembly contains a fixed status portion followed by some
configurable, measurement related content.
The fixed status element is comprised of 22 (UDINT) status DWORDS:
Table 272 - Auxiliary Processor Status
Bit Description Bit Description
0 Connection Fault (managed by controller) 16 +1.5V Power Supply OK
1 Network Fault 17 +1.6V Power Supply OK
2 Network Address Fault 18 DSP 3.3V Power Supply OK
3 DSP Dual Port Memory Fault 19 5V Power Supply OK
4 Recoverable Fault 20 25.5V Power Supply OK
5 Non-recoverable Fault 21 +24V Power Supply OK
6 spare 22 -25.5 Power Supply OK
7 23 -24V Power Supply OK
8 24 AD Ch0&1 +6.5V Power Supply OK
9 25 AD Ch0&1 +5V Reference OK
10 26 spare
11 27
12 28
13 29
14 30 AD Ch0&1 Monitored Power OK
15 Redundant Power Fault 31 AD Ch2&3 Monitored Power OK
