Allen-Bradley 1444-TSCX02-02RB User Manual

354 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Configuration Group 4
Group 4 contains configuration attributes from these objects:
• DC Measurement Object (0x391)
• Tracking Filter Object (0x393)
Table 97 - Configuration Group 4
Source Object Source Instance Source Attribute ID Name Data Type
0x391 1 16 DC Measurement Units ENGUNITS
- - - Pad INT
0x391 1 17 DC Measurement TC REAL
18 DC Measurement Offset REAL
19 DC Measurement Sense Control SINT
20 DC Measurement Type USINT
32 Rod Drop Trigger Source SINT
33 Rod Drop Trigger Angle INT
34 Rod Drop Measurement Range SINT
- - - Pad SINT
- - - Pad INT
0x391 1 35 Rod Drop Decay Time REAL
0x391 2 16 DC Measurement Units ENGUNITS
- - - Pad INT
0x391 2 17 DC Measurement TC REAL
18 DC Measurement Offset REAL
19 DC Measurement Sense Control SINT
20 DC Measurement Type USINT
32 Rod Drop Trigger Source SINT
33 Rod Drop Trigger Angle INT
34 Rod Drop Measurement Range SINT
- - - Pad SINT
- - - Pad INT
0x391 2 35 Rod Drop Decay Time REAL
0x391 3 16 DC Measurement Units ENGUNITS
- 3 - Pad INT
0x391 3 17 DC Measurement TC REAL
18 DC Measurement Offset REAL
19 DC Measurement Sense Control SINT
20 DC Measurement Type USINT
32 Rod Drop Trigger Source SINT
33 Rod Drop Trigger Angle INT
34 Rod Drop Measurement Range SINT
- - - Pad SINT
