Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 383
CIP Objects Appendix A
Configuration Group 29
Group 29 contains configuration attributes from the following objects:
• Current Output Module Object (0x39D)
•Data Manager Object (0x38B)
• Transient Data Manager Object (0x38C)
Table 110 - Configuration Group 29
Source Object Source Instance Source Attribute ID Name Data Type
0x39D 1 18 Current Output 0 Name SINT[32]
2 18 Current Output 1 Name SINT[32]
3 18 Current Output 2 Name
SINT[32]
4 18 Current Output 3 Name SINT[32]
0x38B 1 17 Trend Overall Update Multiplier INT
---Pad INT
0x38B 1 18 Trend Dynamic Update Multiplier DINT
19 Alarm Overall Update Multiplier INT
24 Trend Data-Set Enable BYTE
32 Alarm Data Storage Trigger Source SINT
33 Alarm Data Storage Latching SINT
34 Alarm% Post Trigger for the High Resolution (100 ms)
Overall Records
SINT
35 Alarm% Post Trigger for the Low Resolution (Configured
Rate) Overall Records
SINT
36 Alarm% Post Trigger for Dynamic Data Records (10x
Configured Overall Rate)
SINT
0x38B 1 48 DWORD 0 (Trend Static Data Source) DWORD
49 DWORD 1 (Trend Static Data Source) DWORD
50 DWORD 2 (Trend Static Data Source) DWORD
51 DWORD 3 (Trend Static Data Source) DWORD
0x38C 1 16 Transient Data Mode Control WORD
18 Transient - Dynamic Data Selection SINT
23 Source of Speed Data SINT
24 Low-Speed Threshold DINT
25 High-Speed Threshold DINT
26 Overall Delta RPM (SU) INT
27 Overall Delta RPM (CD) INT
28 Overall Delta RPM (SU) INT
29 Overall Delta RPM (CD) INT
30 Disable Dynamic Data Storage BYTE
- - - Pad SINT
