Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 541
CIP Objects Appendix A
Common Codes and
Structures
Table 314 - Generic CIP Status Codes
Code Name Description
0x00 (0) Success Service was successfully performed by the object specified.
0x01 (1) Connection failure A connection-related service failed along the connection path.
0x02 (2) Resource unavailable Resources are needed for the object to perform the requested service were unavailable.
0x03 (3) Invalid parameter value See Status Code 0x20, which is the preferred value to use for this condition.
0x04 (4) Path segment error The path segment identifier or the segment syntax was not understood by the processing node. Path
processing stops when a path segment error is encountered.
0x05 (5) Path destination unknown The path is referencing an object class, instance, or structure element that is not known or is not
contained in the processing node. Path processing stops when a path destination unknown error is
encountered.
0x06 (6) Partial transfer Only part of the expected data was transferred.
0x07 (7) Connection lost The messaging connection was lost.
0x08 (8) Service not supported The requested service was not implemented or was not defined for this Object Class/Instance.
0x09 (9) Invalid attribute value Invalid attribute data detected.
0x0A (10) Attribute list error An attribute in the Get Attribute List or Set Attribute List response has a nonzero status.
0x0B (11) Already in requested
mode/state
The object is already in the mode/state requested by the service.
0x0C (12) Object state conflict The object cannot perform the requested service in its current mode/state
0x0D (13) Object already exists The requested instance of object to be created already exists.
0x0E (14) Attribute not settable A request to modify a non-modifiable attribute was received.
0x0F (15) Privilege violation A permission/privilege check failed.
0x10 (16) Device state conflict The current mode/state of the device prohibits the execution of the requested service.
0x11 (17) Reply data too large The data to be transmitted in the response buffer is larger than the allocated response buffer.
0x12 (18) Fragmentation of a primitive
value
The service specified an operation that is going to fragment a primitive data value, such as half a
REAL data type.
0x13 (19) Not enough data The service did not supply enough data to perform the specified operation.
0x14 (20) Attribute not supported The attribute that is specified in the request is not supported.
0x15 (21) Too much data The service supplied more data than was expected.
0x16 (22) Object does not exist The object that is specified does not exist in the device.
0x17 (23) Service fragmentation sequence not in progress The fragmentation sequence for this service is not currently active for this data.
0x18 (24) No stored attribute data The attribute data of this object was not saved before the requested service.
0x19 (25) Store operation failure The attribute data of this object was not saved due to a failure during the attempt.
0x1A (26) Routing failure, request packet too large The service request packet was too large for transmission on a network in the path to the
destination. The routing device was forced to abort the service.
0x1B (27) Routing failure, response packet too large The service response packet was too large for transmission on a network in the path from the
destination. The routing device was forced to abort the service.
0x1C (28) Missing attribute list entry data The service did not supply an attribute in a list of attributes that the service needed to perform the
requested behavior.
0x1D (29) Invalid attribute value list The service is returning the list of attributes that are supplied with status information for those
attributes that were invalid.
