CIP Objects Appendix A
Configuration Groups 20 and 21
Group 20 contains configuration attributes from the FFT Band Object
(0x399) Instances 5…18.
Group 21 contains configuration attributes from the FFT Band Object
(0x399) Instances 19…32.
0x399 4 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
0x399 4 19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
Table 101 - Configuration Group 19 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
Table 102 - Configuration Groups 20 and 21
Source Object Source Instance Source Attribute ID Name Data Type
0x399 5/19 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
0x399 6/20 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
