Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 535
CIP Objects Appendix A
Quality of Service Object
The Quality of Service Object (class code 0x48) is part of the standard
Hilscher netX100 EIP protocol stack. Before ODVA testing, this object is
completed/updated in line with the latest stack released by Hilscher.
Table 298 - Object Instances
Instance
ID
Description
0 Class Instance of QoS Object
1 Instance 1 of the QoS Object
Table 299 - Class Attributes
Attribute
ID
Access
Rule
NV Name Data
Type
Description of
Attribute
Semantics of
Values
1 Get NV Revision USINT Defines the current revision of
the QoS Object
Current Revision: 1
2 Get NV Maximum
instance
USINT 1
Table 300 - Instance Attributes
Attribute
ID
Access
Rule
NV Name Data Type Description of
Attribute
1 Get V 802.1Q Tag Enable USINT Virtual LAN Tagging
4 Get V DSCP Urgent USINT Differentiated Services Code Point
5 Get V DSCP Scheduled USINT
6 Get V DSCP High USINT
7GetVDSCP LowUSINT
8 Get V DSCP Explicit USINT
Table 301 - Common Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x0E x x Get Attribute Single
0x10 - x Set Attribute Single
