Appendix A CIP Objects
Parameter – Tag – Object
Attribute Cross-reference
Tab le 83 maps the parameters on each page of the AOP to its controller tag and
to the specific object attribute of the module that it populates.
Ethernet Link Object 537
Nonvolatile Storage Object 539
Common Object Content
Common Codes and Structures 541
Topic Page
Table 83 - Parameter – Tag – Object Attribute Cross-reference
Parameter Tag Member Object Attribute
Define Module Functionality
Power Supply ModuleControl.RedundantPowerSupply Dynamix Module Control Object Redundant Power Supply
Personality Module.PersonalityApplied Dynamix Configuration Manager
Object
AOP Module Type
Speed Page
Mode ModuleControl.TachoMode Dynamix Module Control Object Tacho Mode
Name TachName[0…1] Dynamix Tacho and Speed
Measurement Object
Tach 0 Name…Tach 1 Name
Speed Multiplier Speed[0…1].Multiplier Dynamix Tacho and Speed
Measurement Object
Speed Multiplier
Source Speed[0…1].TachSource Dynamix Tacho and Speed
Measurement Object
Tacho Source
TTL Trigger Speed[0…1].TachTriggerSlope Dynamix Tacho and Speed
Measurement Object
Tacho Trigger
Acceleration Update Rate Speed[0…1].AccelUpdateRate Dynamix Tacho and Speed
Measurement Object
ROC Delta Time
Acceleration Time Constant Speed[0…1].AccelTimeConstant Dynamix Tacho and Speed
Measurement Object
ROC TC
Tachometer Page
Transducer Type Tach[0…1].SensorType Dynamix TSC Module Object Input Sensor Type
Transducer Power Tach[0…1].Power Dynamix TSC Module Object Sensor Power Supply
Auto Trigger Tach[0…1].AutoTrigger Dynamix TSC Module Object Trigger Mode
Trigger Level Tach[0…1].TriggerLevel Dynamix TSC Module Object Trigger Threshold
Trigger Slope Tach[0…1].TriggerSlope Dynamix TSC Module Object Trigger Slope/Edge
Pulses per Revolution Tach[0…1].PulsePerRevolution Dynamix TSC Module Object Sensor Target, Pulses Per Revolution
DC volts Fault Tach[0…1].DCVFault Dynamix TSC Module Object Sensor OK Definition
Fault High Limit (V DC) Tach[0…1].FaultHLimit Dynamix TSC Module Object Sensor OK High Threshold
Fault Low Limit (V DC) Tach[0…1].FaultLLimit Dynamix TSC Module Object Sensor OK Low Threshold
Speed Fault Tach[0…1].SpeedFault Dynamix TSC Module Object Sensor OK Definition
Speed High Limit Tach[0…1].SpeedHLimit Dynamix TSC Module Object High RPM Threshold
Speed Low Limit Tach[0…1].SpeedLLimit Dynamix TSC Module Object Low RPM Threshold
Tach Expansion Module Fault Tach[0…1].ExpansionModuleFault Dynamix TSC Module Object Sensor OK Definition
