Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 503
CIP Objects Appendix A
Dynamix Current Output
Module Object
The Current Output Module Object (class code 0x39D) configures the
4…20 mA current outputs of the single supported current output expansion
module.
This object defines the setup for the Current Output expansion module and
interaction of this expansion module with main module.
Table 252 - Object Instances
Instance ID Description
0 Current Output Module Class Instance
1 Instance 1 - Current Output 0
2 Instance 2 - Current Output 1
3 Instance 3 - Current Output 2
4 Instance 4 - Current Output 3
Table 253 - Class Attributes
Attribute ID Access
Rule
NV Name Data Type Description of Attribute Semantics of Values
1 Get NV Revision UINT Current object revision. Current revision.
11 Get NV Firmware Revision STRUCT Retrieves Firmware Revision of
the current output module.
Firmware Revision information
11 Get NV Major Version USINT
11 Get NV Minor Version USINT
12 Get V Expansion Module Status WORD Coded information on TSC
Analog Output Module
operational status.
Analog Output Module
13 Get NV Serial Number SHORT_STRING Warranty Serial Number 14 character max.
14 Get NV Product Name SHORT_STRING 1444-AOFX-00-04RB
15 Get V Current Module Control BYTE Configuration of generic current
output module behavior in case
of detected fault condition.
Set to zero
Use only instance attribute 24,
configurable per output channel.
16 Get NV Auxiliary Link-Time Out UINT Link timeout. Fixed at 1000 ms (1s)
