CIP Objects Appendix A
Configuration Group 22
Group 22 contains configuration attributes from the following objects:
• Transducer Object (0x38E)
• Tacho and Speed Measurement Object (0x395)
Table 103 - Configuration Group 22
Source Object Source Instance Source Attribute ID Name Data Type
0x38E 1 16 Transducer Name SINT[32]
17 Transducer Orientation INT
18 Transducer Location SINT
19 Transducer Output Sense SINT
0x38E 2 16 Transducer Name SINT[32]
17 Transducer Orientation INT
18 Transducer Location SINT
19 Transducer Output Sense SINT
0x38E 3 16 Transducer Name SINT[32]
17 Transducer Orientation INT
18 Transducer Location SINT
19 Transducer Output Sense SINT
0x38E 4 16 Transducer Name SINT[32]
17 Transducer Orientation INT
18 Transducer Location SINT
19 Transducer Output Sense SINT
0x395 1 18 Tacho 0 Name SINT[32]
0x395 2 18 Tacho 1 Name SINT[32]
