Chapter 10 Operate the Module
Input Data Structure
The input data structure is written immediately following the status data. It
consists of an array of 4 byte floating point numbers that represent the various
measurements that are selected for input in Module Definition.
The parameters are some subset of the parameters that are listed in Tabl e 70
.
Table 70 - Input Data Parameters
# Parameter Description
0 Ch0Overall0 Overall values after integration and high pass filters
1Ch1Overall0
2Ch2Overall0
3Ch3Overall0
4Ch0Overall1
Optional Overall values from selected data source
5Ch1Overall1
6Ch2Overall1
7Ch3Overall1
8 Ch0DCV Channel bias (or gap) values
9 Ch1DCV
10 Ch2DCV
11 Ch3DCV
12 Ch0Order0Mag
Tracking filter 0 magnitude values
13 Ch1Order0Mag
14 Ch2Order0Mag
15 Ch3Order0Mag
16 Ch0Order0Phase Tracking filter 0 phase values
17 Ch1Order0Phase
18 Ch2Order0Phase
19 Ch3Order0Phase
20 Ch0Order1Mag
Tracking filter 1 magnitude values
21 Ch1Order1Mag
22 Ch2Order1Mag
23 Ch3Order1Mag
24 Ch0Order1Phase Tracking filter 1 phase values
25 Ch1Order1Phase
26 Ch2Order1Phase
27 Ch3Order1Phase
28 Ch0Order2Mag
Tracking filter 2 magnitude values
29 Ch1Order2Mag
30 Ch2Order2Mag
31 Ch3Order2Mag
