Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 359
CIP Objects Appendix A
Configuration Group 17
Group 17 contains voted alarm object class attributes and instances 1…7.
0x396 N+1 46 Range 3 - Alarm Multiplier REAL
47 Range 4 - upper control value REAL
48 Range 4 - Alarm Multiplier REAL
49 Range 5 - upper control value REAL
50 Range 5 - Alarm Multiplier REAL
64 Profile mode - Reference for Low Alert Threshold SINT
65 Profile mode - Reference for High Alert Threshold SINT
66 Profile mode - Reference for Low Danger Threshold SINT
67 Profile mode - Reference for High Danger Threshold SINT
Table 98 - Configuration Groups 5...16 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
Table 99 - Configuration Group 17
Source Object Source Instance Source Attribute ID Name Data Type
0x397 0 16 Trip Inhibit/Bypass Source BYTE
17 Alarm Reset Source BYTE
- - - Pad INT
0x397 1 16 Alarm Usage BYTE
18 Alarm Behavior SINT
19 Alarm Type SINT
24 Alarm Logic Configuration SINT
25 Alarm Input 0 SINT
26 Alarm Input 1 SINT
27 Alarm Input 2 SINT
28 Alarm Input 3 SINT
32 Alarm Multiplier Control BYTE
- - - Pad SINT
- - - Pad INT
0x397 1 33 Alarm Multiplier ON Time DINT
40 Speed Gating Control SINT
41 Speed Gating Detection SINT
- - - Pad INT
