CIP Objects Appendix A
Ethernet Link Object
The Ethernet Link Object (class code 0xF6) is part of the standard Hilscher
netX100 EIP protocol stack. Before ODVA testing, this object is completed/
updated in line with the latest stack released by Hilscher.
The Ethernet Link Object maintains link-specific counters and status
information for an Ethernet communication interface.
A request to access instance 1 of the Ethernet Link Object refers to the instance
associated with the communication interface over which the request was
received.
10 Get/Set NV Select ACD BOOL Address Conflict Detection
11 Get/Set NV Last Conflict Detected STRUCT Structure of 35 USINT
13 Get/Set NV Encapsulation Inactivity
Timeout
UINT Timeout in seconds
(1-3600)
0 =
Disabled
Default =
120 s
Table 304 - Instance Attributes (continued)
Attribute
ID
Access
Rule
NV Name Data Type Description of
Attribute
Semantics of
Values
Table 305 - Common Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x01 - x Get Attributes All Returns the contents of the specified attributes
0x0E x x Get Attribute Single Returns the contents of the specified attribute
0x10 - x Set Attribute Single Sets the specified attribute
Table 306 - Object Instances
Instance ID Description
0 Ethernet Link Class Instance
1 Instance representing port 1
2 Instance representing port 2
Table 307 - Class Attributes
Attribute
ID
Access
Rule
NV Name Data Type Description of
Attribute
Semantics of
Values
1 Get NV Revision UINT Current revision of this
Object
Current revision:
3
2 Get V Maximum Instance UINT 2
3GetVNumber of
Instances
UINT 2
