516 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Attribute Semantics
Firmware Revision
Identity Object instance attribute 4 (and vendor-specific attribute 102) refer
directly to the netX (communication) processor firmware revision but also
reflect an overall version identification for a firmware release. A breakdown of
the associated Firmware Revisions included in a release is tabulated in the
following table.
Hardware Revision
Identity Object instance attribute 101 is a vendor-specific attribute that is used
to identify the hardware revision. The correlation between that revision and
the product label is tabulated in the following table.
Message Router Object
The Message Router Object (class code 0x02) provides a messaging connection
point through which a client can address a service to any object class or
instance residing in the physical device.
This object is part of the standard Hilscher netX100 EIP protocol stack.
No attributes are implemented and no services are supported.
Release netX DSP Auxiliary
Relay
Auxiliary
4-20mA
Auxiliary TSCX
2.001.2 2.001.2 1.01.02 3.10 3.10 3.10
2.001.7 2.001.7 1.01.08 3.10 3.10 3.13
3.001.3 3.001.3 1.02.6 3.10 3.10 3.63
Hardware Revision (major/minor/sub-minor) Product Label
6.3 A
Table 268 - Common Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x01 x x Get_Attributes_All Returns the contents of the specified
attributes
0x05 x x Reset Invokes the reset service for the device
0x0E x x Get Attribute Single Returns the contents of the specified
attribute
