Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 543
CIP Objects Appendix A
Engineering Units
The module supports a subset of the standard and custom CIP Engineering
unit lists, appropriate to the selected Channel Application Type.
0x1004 Dynamic data requests and special service requests are not allowed while the module is in Program Mode (while the module is being
configured).
0x1E Embedded service error. The requested inter-processor message exchange (NetX to DSP and/or to an auxiliary module) failed to
complete so the requested data cannot be returned.
0x20 <0x1FFFFFFF Invalid parameter in one or more configuration groups.
Bits 0 to 28 represent groups 1 to 29, if a group is in error the appropriate bit is set to 0/cleared.
Example: 0x1FFCFFFF
Ox1FFFFFFF - 0x1FFCFFFF = 0x300000
As binary: 11 0000 0000 0000 0000
So: Groups 17/18
General Code Extended
Code
Description
Table 315 - CIP Engineering Unit List
Value/ID Index Name Description
0x1200 24 °C Temperature measurement application types (There is no conversion between temperature
units, separate application types apply to each).
0x1201 22 °F
0x1202 23 K
0x1300 16 psi Dynamic pressure measurement application.
0x1307 14 bar
0x1308 15 mbar
0x1309 19 Pa
0x130A 18 kPa
0x0C00 17 MPa
0x1500 12 m/s
2
Vibration acceleration measurement applications.
0x1502 37 in./s
2
0x1504 10 g
0x0B00 8 mm/s
2
0x0B01 11 mg
0x0A00 (10) gSE Spike energy measurement application.
0x1703 - degree Phase angle measurement (orders/SMAX).
0x1C00 20 A Current measurement application types.
0x1C02 21 mA
0x1F0F - RPM Available only when the application uses one or more of the two available tacho inputs
0x0F01 - RPM/min
