Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 105
System Operation and Configuration Chapter 4
Table 86 - Digital Expansion Module 2 Output Relay Communication Fault Value (Parameter 331)
Digital Expansion Module 2 Output Relay Final Fault Value (Parameter 566)
Digital Expansion Module 2 Output Relay Final Fault Value (Parameter 566) is
available in E300 relay firmware v5.000 and higher. This parameter defines which
state both output relays should go to when communication is not restored with
the time defined in Fault Mode Output State Duration (Parameter 561).
Table 87 - Digital Expansion Module 2 Output Relay Final Fault Value (Parameter 566)
Digital Expansion Module 3 Output Relay Communication Fault Action (Parameter 336)
Digital Expansion Module 3 Output Relay Communication Fault Action
(Parameter 336) defines how both output relays on Digital Expansion Module 3
responds when a communication fault occurs.
Table 88 - Digital Expansion Module 3 Output Relay Communication Fault Action (Parameter 336)
Digital Expansion Module 3 Output Relay Communication Fault Value (Parameter 337)
Digital Expansion Module 3 Output Relay Communication Fault Value
(Parameter 337) defines which state both output relays should go to when a
communication fault occurs.
Table 89 - Digital Expansion Module 3 Output Relay Communication Fault Value (Parameter 337)
Digital Expansion Module 3 Output Relay Final Fault Value (Parameter 567)
Digital Expansion Module 3 Output Relay Final Fault Value (Parameter 567) is
available in E300 relay firmware v5.000 and higher. This parameter defines which
state both output relays should go to when communication is not restored with
the time defined in Fault Mode Output State Duration (Parameter 561).
Value Assignment Description
0 Open Open Digital Expansion Module 2 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 2 Output Relay 0 and Output Relay 1
Value Assignment Description
0 Open Open Digital Expansion Module 2 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 2 Output Relay 0 and Output Relay 1
Value Assignment Description
0GoToCommFltValue
Set to Digital Expansion Module 3 Output Relay Communication Fault
Value (Parameter 337)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
Value Assignment Description
0 Open Open Digital Expansion Module 3 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 3 Output Relay 0 and Output Relay 1
