Rockwell Automation Publication 193-UM015E-EN-P - October 2015 61
Installation and Wiring Chapter 2
Fuse Coordination
The following tables list Type I and Type II Fuse Coordination when used with
Bulletin 100-C and 100-D and Bulletin 500 NEMA Size 00… 4 Contactors.
Table 18 - Type 1 and Type II fuse coordination with Bul. 100-C and 100-D contactors per
EN60947-4-1
Table 19 - Type 1 and Type II fuse coordination with Bul. 500 NEMA contactors
per EN60947-4-1
Typical Motor Connections
ATTENTION: Select the motor branch circuit protection that complies with the
NEC and any other governing regional or local codes.
Overload Relay with
Sensing Module Cat. No.
Contactor Cat.
No.
Max. Starter
FLC[A]
Prospective Short-Circuit
Current, I
r
[A]
Conditional Short-
Circuit Current, I
q
[A]
Max. Voltage
[V]
Type I Class J or
CC Fuse [A]
Type II Class J
or CC Fuse [A]
193-ESM-___-30A-C23 100-C09 9 1000 100,000 600 20 15
100-C12 12 20 20
100-C16 16 30 30
100-C23 23 3,000 40 40
193-ESM-___-30A-C55,
193-ESM-___-60A-C55
100-C30 30 50 50
100-C37 37 50 50
100-C43 43 70 70
100-C55 55 80 80
193-ESM-___-100A-C97 100-C60 60 5,000 80 80
100-C72 72 100 100
100-C85 85 150 150
100-C97 97 200 200
193-ESM-___-200A-D180 100-D115 115 5,000 100,000 600 200 200
100-D140 140 10,000 250 250
100-D180 180 300 300
Overload Relay with Sensing
Module Cat. No. Contactor Size Max. Starter FLC[A]
Prospective Short-
Circuit Current, I
r
[A]
Conditional Short-
Circuit Current, I
q
[A]
Max. Voltage
[V]
Type I Class J
Fuse [A]
Type II Class J
Fuse [A]
592-ESM-___-30A-S2 0 18 3,000 100,000 600 30 30
592-ESM-___-30A-S2 1 27 30 30
592-ESM-___-60A-S2 2 45 60 60
592-ESM-___-100A-S3 3 90 5,000 200 200
592-ESM-___-200A-S4 4 135 10,000 240 500 500
600 400 400
ATTENTION: When working on energized circuits, DO NOT rely on voltage and
current information that is provided by the E300 relay for personal safety.
Always use a portable voltage or current measurement device to measure the
signal locally.
