Rockwell Automation Publication 193-UM015E-EN-P - October 2015 685
EtherNet/IP Information Appendix D
Table 595 - Assembly Object Class Attributes
The following static assembly instance attributes are supported for each assembly
instance.
Table 596 - Assembly Instance Attributes
The following services are implemented for the Assembly Object.
Table 597 - Assembly Object Services
The following table summarizes the various instances of the Assembly Object
that are implemented:
Table 598 - Assembly Object Instance Summary
Attribute ID Access Rule Name Data Type Value
2 Get Max. Instance UINT 199
Attribute ID Access Rule Name Data Type Value
1Get
Number of Members in
Member List
UINT
2Get
Member List Array of STRUCT Array of CIP paths
Member Data
Description
UINT Size of Member Data in bits
Member Path Size UINT Size of Member Path in bytes
Member Path Packed EPATH Member EPATHs for each assembly instance
3 Conditional Data Array of BYTE
4 Get Size UINT Number of bytes in attribute 3
100 Get Name String STRING
Service Code
Implemented for:
Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Inst Type Name Description
2 Consumed Trip Reset Cmd Required ODVA Consumed Instance
50 Produced Trip Status Required ODVA Produced Instance
120 Config Configuration Configuration Assembly
144 Consumed E300 Consumed Default Consumed Assembly
198 Produced Current Diags Produced Assembly with Current Diagnostics Only
199 Produced All Diags Default Produced Assembly
