120 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 4 System Operation and Configuration
Table 125 - Analog Input Data Format for Resistance Input Type
Analog Output Channel
The isolated analog output can be programmed to provide one of the following
analog output signal types:
• Current
– 4…20 mA
– 0…20 mA
RTD
120 Ω Ni 672
260.0 °C High Limit 2600 260 32767 16383
260.0 °C High Range 2600 260 32767 16383
-80.0 °C Low Range -800 -80 -32768 0
-80.0 °C Low Limit -800 -80 -32768 0
500.0 °F High Limit 5000 500 32767 16383
500.0 °F High Range 5000 500 32767 16383
-112.0 °F Low Range -1120 -112 -32768 0
-112.0 °F Low Limit -1120 -112 -32768 0
RTD
100 Ω NiFe
518
200.0 °C High Limit 2000 200 32767 16383
200.0 °C High Range 2000 200 32767 16383
-100.0 °C Low Range -1000 -100 -32768 0
-100.0 °C Low Limit -1000 -100 -32768 0
392.0 °F High Limit 3920 392 32767 16383
392.0 °F High Range 3920 392 32767 16383
-148.0 °F Low Range -1480 -148 -32768 0
-148.0 °F Low Limit -1480 -148 -32768 0
Input Range Input Value Condition
Engineering
Units
Engineering
Units x 10
Raw /
Proportional
PID
Resistance
0-150 Ω
150.00 Ω High Limit 15000 1500 32767 16383
150.00 Ω High Range 15000 1500 32767 16383
0.00 Ω Low Range 0 0 -32768 0
0.00 Ω Low Limit 0 0 -32768 0
Resistance
0-750 Ω
750.0 Ω High Limit 7500 750 32767 16383
750.0 Ω High Range 7500 750 32767 16383
0.0 Ω Low Range 0 0 -32768 0
0.0 Ω Low Limit 0 0 -32768 0
Resistance
0-3000 Ω
3000.0 Ω High Limit 30000 3000 32767 16383
3000.0 Ω High Range 30000 3000 32767 16383
0.0 Ω Low Range 0 0 -32768 0
0.0 Ω Low Limit 0 0 -32768 0
Resistance
0-6000 Ω
(PTC / NTC)
6000 Ω High Limit 6000 600 32767 16383
6000 Ω High Range 6000 600 32767 16383
0 Ω Low Range 0 0 -32768 0
0 Ω Low Limit 0 0 -32768 0
Input Range Input Value Condition
Engineering
Units
Engineering
Units x 10
Raw /
Proportional
PID
