Rockwell Automation Publication 193-UM015E-EN-P - October 2015 429
Protective Trip and Warning Functions Chapter 6
Any relay outputs configured as a Trip Alarm closes
Any relay outputs configured as a Normal Relay are placed in their
Prote
ction Fault state (if so programmed)
Thermistor (PTC) Warning
The E300 relay provides a thermistor (PTC) warning indication if:
No trip currently exists
Resistance of the thermistor (PTC) sensors is greater than 3400
If
the E300 relay warns on a thermistor (PTC), the following occurs:
T
he TRIP/WARN LED flashes a yellow 3-long / 2-short blink pattern
Bit 1 in Control Warning Status (Parameter 13) sets to 1
Bit 1 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Warning Alarm closes
DeviceLogix Protection
An E300 relay with firmware v5.000 or higher has a DeviceLogix logic engine.
You can create custom logic programs for distributed motor control applications.
See Chapter 9
for more information on DeviceLogix. DeviceLogix provides you
with the capability to create a customized protection algorithm that can generate
a trip or warning event.
IMPORTANT
The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
Output PT00 Protection Fault Action (Parameter 304)
Output PT00 Protection Fault Value (Parameter 305)
Output PT01 Protection Fault Action (Parameter 310)
Output PT01 Protection Fault Value (Parameter 311)
Output PT02 Protection Fault Action (Parameter 316)
Output PT02 Protection Fault Value (Parameter 317)
Output Digital Module 1 Protection Fault Action (Parameter 322)
Output Digital Module 1 Protection Fault Value (Parameter 323)
Output Digital Module 2 Protection Fault Action (Parameter 328)
Output Digital Module 2 Protection Fault Value (Parameter 329)
Output Digital Module 3 Protection Fault Action (Parameter 334)
Output Digital Module 3 Protection Fault Value (Parameter 335)
Output Digital Module 4 Protection Fault Action (Parameter 340)
Output Digital Module 4 Protection Fault Value (Parameter 342)
