Rockwell Automation Publication 193-UM015E-EN-P - October 2015 489

Metering and Diagnostics Chapter 8

Current Trip Status

Current Trip Status (Parameter 4) reports the status of the current-based

protective trip functions.

Table 423 - Current Trip Status (Parameter 4)

Bit

1514131211109876543210 Function

XOverload Trip

X Phase Loss Trip

X Ground Fault Current Trip

X Stall Trip

X Jam Trip

X Underload Trip

X Current Imbalance Trip

X L1 Under Current Trip

X L2 Under Current Trip

X L3 Under Current Trip

X L1 Over Current Trip

X L2 Over Current Trip

X L3 Over Current Trip

X L1 Line Loss Trip

X L2 Line Loss Trip

X L3 Line Loss Trip
