Allen-Bradley E300 User Manual

536 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 8 Metering and Diagnostics
Table 532 - Analog Module 2 Status (Parameter 124)
Analog Module 3
Analog Module 3 – Input Channel 00
Analog Module 3 – Input Channel 00 (Parameter 117) reports the monitored
value of Analog Module 3 – Input Channel 00.
Table 533 - Analog Module 3 – Input Channel 00 (Parameter 117)
Analog Module 3 – Input Channel 01
Analog Module 3 – Input Channel 01 (Parameter 118) reports the monitored
value of Analog Module 3 – Input Channel 01.
Bit
Function
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
XInput Channel 00 Open Circuit
XInput Channel 00 Over Range
XInput Channel 00 Under Range
XInput Channel 01 Open Circuit
XInput Channel 01 Over Range
XInput Channel 01 Under Range
XInput Channel 02 Open Circuit
XInput Channel 02 Over Range
XInput Channel 02 Under Range
XOutput Channel 00 Open Circuit
XOutput Channel 00 Hold Last State Mode Active
XOutput Channel 00 Over Range
XOutput Channel 00 Under Range
XAnalog Module Configured
XAnalog Module Warning (Module Number Dial Changed)
XAnalog Module Faulted
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
