Rockwell Automation Publication 193-UM015E-EN-P - October 2015 107
System Operation and Configuration Chapter 4
Output Relay 0 Communication Idle Action (Parameter 308)
Output Relay 0 Communication Idle Action (Parameter 308) defines how
Output Relay 0 when assigned as a Normal/General Purpose Relay or Control/
Control & Trip Relay responds when a network scanner goes into Idle Mode or a
programmable logic controller (PLC) goes into Program Mode.
Table 94 - Output Relay 0 Communication Idle Action (Parameter 308)
Output Relay 0 Communication Idle Value (Parameter 309)
Output Relay 0 Communication Idle Value (Parameter 309) defines which state
Output Relay 0 should go to when a network scanner goes into Idle Mode or a
PLC goes into Program Mode.
Table 95 - Output Relay 0 Communication Idle Value (Parameter 309)
Output Relay 1 Communication Idle Action (Parameter 314)
Output Relay 1 Communication Idle Action (Parameter 314) defines how
Output Relay 1 when assigned as a Normal/General Purpose Relay or Control/
Control & Trip Relay responds when a network scanner goes into Idle Mode or a
PLC goes into Program Mode.
Table 96 - Output Relay 1 Communication Idle Action (Parameter 314)
Output Relay 1 Communication Idle Value (Parameter 315)
Output Relay 1 Communication Idle Value (Parameter 315) defines which state
Output Relay 1 should go to when a network scanner goes into Idle Mode or a
PLC goes into Program Mode.
Table 97 - Output Relay 1 Communication Idle Value (Parameter 315)
Value Assignment Description
0 GoToCommFltValue Set to Output Relay 0 Communication Idle Value (Parameter 309)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
Value Assignment Description
0Open Open Output Relay 0
1 Closed Close Output Relay 0
Value Assignment Description
0 GoToCommIdlValue Set to Output Relay 1 Communication Idle Value (Parameter 315)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
Value Assignment Description
0Open Open Output Relay 1
1 Closed Close Output Relay 1
