Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 109
System Operation and Configuration Chapter 4
Digital Expansion Module 2 Output Relay Communication Idle Action (Parameter 332)
Digital Expansion Module 2 Output Relay Communication Idle Action
(Parameter 332) defines how both output relays on Digital Expansion Module 2
responds when network scanner goes into Idle Mode or a PLC goes into Program
Mode.
Table 102 - Digital Expansion Module 2 Output Relay Communication Idle Action (Parameter 332)
Digital Expansion Module 2 Output Relay Communication Idle Value (Parameter 333)
Digital Expansion Module 2 Output Relay Communication Idle Value
(Parameter 333) defines which state both output relays should go to when a
network scanner goes into Idle Mode or a PLC goes into Program Mode.
Table 103 - Digital Expansion Module 2 Output Relay Communication Idle Value (Parameter 333)
Digital Expansion Module 3 Output Relay Communication Idle Action (Parameter 338)
Digital Expansion Module 3 Output Relay Communication Idle Action
(Parameter 338) defines how both output relays on Digital Expansion Module 3
responds when a network scanner goes into Idle Mode or a PLC goes into
Program Mode.
Table 104 - Digital Expansion Module 3 Output Relay Communication Idle Action (Parameter 338)
Digital Expansion Module 3 Output Relay Communication Idle Value (Parameter 339)
Digital Expansion Module 3 Output Relay Communication Idle Value
(Parameter 339) defines which state both output relays should go to when a
network scanner goes into Idle Mode or a PLC goes into Program Mode.
Table 105 - Digital Expansion Module 3 Output Relay Communication Idle Value (Parameter 339)
Value Assignment Description
0 GoToCommIdlValue
Set to Digital Expansion Module 2 Output Relay Communication Idle
Value (Parameter 333)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
Value Assignment Description
0 Open Open Digital Expansion Module 2 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 2 Output Relay 0 and Output Relay 1
Value Assignment Description
0 GoToCommIdlValue
Set to Digital Expansion Module 3 Output Relay Communication Idle
Value (Parameter 339)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
Value Assignment Description
0 Open Open Digital Expansion Module 3 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 3 Output Relay 0 and Output Relay 1
