Allen-Bradley E300 User Manual

436 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 6 Protective Trip and Warning Functions
• No warning currently exists
• Number of Starts Warning is enabled
• The value in
Starts Counter (Parameter 29) is greater than the value set in
Tot
al Starts (Parameter 207)
If the E300 relay warns on a number of starts warning, the following occurs:
• The TRIP/WARN LED flashes a yellow 3-long / 12-short blink pattern
• Bit 11 in Control Warning Status (Parameter 13) sets to 1
• Bit 1 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Warning Alarm close
Total Starts
Total Starts (Parameter 207) allows you to set the number starts until the starts
counter warning occurs.
Table 373 - Total Starts (Parameter 207)
Starts Counter
Starts Counter (Parameter 29) represents the number of times a motor has been
started. This value can be reset to zero using the Clear Command (Parameter
165) function Clear Operating Statistics.
Table 374 - Starts Counter (Parameter 29)
Operating Hours Warning
The E300 relay warns with an operating hours warning indication if:
• No warning currently exists
• Operating Hours Warning is enabled
Default Value 0
Minimum Value 0
Maximum Value 65535
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value 0
Maximum Value 65535
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units
