Rockwell Automation Publication 193-UM015E-EN-P - October 2015 445
Protective Trip and Warning Functions Chapter 6
The measured analog input signal is greater than the Analog Module 1
Channel 00 Trip Level for a time period greater than the Analog Module 1
– Channel 00 Over Level Trip Delay.
If the E300 relay trips on an Analog Module 1 – Channel 00 Over Level, the:
T
RIP/WARN LED status indicator flashes a red 4-long / 1-short blink
patter
n
Bit 0 in Analog Trip Status (Parameter 8) sets to 1
Bit 0 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Trip Relay open
Any relay outputs configured as a Control Relay open
Any relay outputs configured as a Trip Alarm close
Any relay outputs configured as a Normal Relay are placed in their
P
rote
ction Fault state (if so programmed)
Analog Module 1 – Channel 00 Over Level Trip Delay
Analog Module 1 – Channel 00 Over Level Trip Delay (Parameter 443) allows
you to define the time period an Analog Module 1 – Channel 00 Over Level
condition must be present before a trip occurs. It is adjustable from 0.1…25.0
seconds.
IMPORTANT
The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
Output PT00 Protection Fault Action (Parameter 304)
Output PT00 Protection Fault Value (Parameter 305)
Output PT01 Protection Fault Action (Parameter 310)
Output PT01 Protection Fault Value (Parameter 311)
Output PT02 Protection Fault Action (Parameter 316)
Output PT02 Protection Fault Value (Parameter 317)
Output Digital Module 1 Protection Fault Action (Parameter 322)
Output Digital Module 1 Protection Fault Value (Parameter 323)
Output Digital Module 2 Protection Fault Action (Parameter 328)
Output Digital Module 2 Protection Fault Value (Parameter 329)
Output Digital Module 3 Protection Fault Action (Parameter 334)
Output Digital Module 3 Protection Fault Value (Parameter 335)
Output Digital Module 4 Protection Fault Action (Parameter 340)
Output Digital Module 4 Protection Fault Value (Parameter 342)
