Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 461
Protective Trip and Warning Functions Chapter 6
condition must be present before a trip occurs. It is adjustable from 0.1…25.0
seconds.
Table 399 - Analog Module 3 – Channel 00 Over Level Trip Delay (Parameter 505)
Analog Module 3 – Channel 00 Trip Level
Analog Module 3 – Channel 00 Trip Level (Parameter 506) allows you to define
the magnitude of the analog signal in which the E300 relay trips on an Analog
Module 3 – Channel 00 Over Level trip. It is user-adjustable from -
32768…+32767.
Table 400 - Analog Module 3 – Channel 00 Trip Level (Parameter 506)
Analog Module 3 – Channel 00 Over Level Warning
The E300 relay indicates an Analog Module 3 – Channel 00 Over Level warning
if:
• N
o warning currently exists
• Analog Module 3 – Channel 00 Over Level Warning is enabled
• The maximum phase current is equal to or greater than the Analog
Modu
le 3 – Channel 00 Warning Level
When the Analog Module 3 – Channel 00 Over Level Warning conditions are
satis
fied, the:
• TRIP/WARN LED flashes a yellow 4-long / 7-short blink pattern
• Bit 6 in Analog Warning Status (Parameter 14) sets to 1
• Bit 1 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Warning Alarm close
Analog Module 3 – Channel 00 Warning Level
Analog Module 3 – Channel 00 Warning Level (Parameter 507) allows you to
define the magnitude of the analog signal in which the E300 relay trips on an
Default Value 1.0
Minimum Value 0.1
Maximum Value 25.0
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 10
Units Seconds
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
