Chapter 6 Protective Trip and Warning Functions
Analog Module 4 – Channel 00 Over Level Trip Delay
Analog Module 4 – Channel 00 Over Level Trip Delay (Parameter 536) allows
you to define the time period an Analog Module 4 – Channel 00 Over Level
condition must be present before a trip occurs. It is adjustable from 0.1…25.0
seconds.
Table 408 - Analog Module 4 – Channel 00 Over Level Trip Delay (Parameter 536)
Analog Module 4 – Channel 00 Trip Level
Analog Module 4 – Channel 00 Trip Level (Parameter 537) allows you to define
the magnitude of the analog signal in which the E300 relay trips on an Analog
Module 4 – Channel 00 Over Level trip. It is user-adjustable from -
32768…+32767.
The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
• Output PT00 Protection Fault Action (Parameter 304)
• Output PT00 Protection Fault Value (Parameter 305)
• Output PT01 Protection Fault Action (Parameter 310)
• Output PT01 Protection Fault Value (Parameter 311)
• Output PT02 Protection Fault Action (Parameter 316)
• Output PT02 Protection Fault Value (Parameter 317)
• Output Digital Module 1 Protection Fault Action (Parameter 322)
• Output Digital Module 1 Protection Fault Value (Parameter 323)
• Output Digital Module 2 Protection Fault Action (Parameter 328)
• Output Digital Module 2 Protection Fault Value (Parameter 329)
• Output Digital Module 3 Protection Fault Action (Parameter 334)
• Output Digital Module 3 Protection Fault Value (Parameter 335)
• Output Digital Module 4 Protection Fault Action (Parameter 340)
• Output Digital Module 4 Protection Fault Value (Parameter 342)
Default Value 1.0
Minimum Value 0.1
Maximum Value 25.0
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 10
Units Seconds
