Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 51
Installation and Wiring Chapter 2
Table 5 - E300 Control Module Wire Size and Torque Specifications
Figure 41 - Control Module Wiring
Wire Type Conductor Torque Cat. No.
193-EIO-_ _-_ _ _
193-EIOGP-_ _-_ _ _
Stranded/Solid [AWG] Single 24...12 AWG
4lb-in
Multiple
(stranded only)
24...16 AWG
4 lb-in
Flexible-Stranded with Ferrule
Metric
Single 0.25…2.5 mm
2
0.45 N•m
Multiple 0.5...0.75 mm
2
0.45 N•m
Coarse-Stranded/Solid Metric Single 0.2...2.5 mm
2
0.45 N•m
Multiple 0.2...1.5 mm
2
0.45 N•m
R24R23
RELAY 2RELAY 1
R14R13
IN3
IN2
Additional Inputs for 193-EIO-63-_ _ _
IN0
IN1
A2
PE
A1A1
A1
R03
R04
A2
IN5
IN4
(+)
(-)
RELAY 0
S2S1
RELAY 1
R14R13
IN3
IN2
IN0
IN1
A2
A1A1
A1
R03
R04
A2
IT2
IT1
(+)
(-)
RELAY 0
193-EIOGP-_ _-_ _ _193-EIO-_ _-_ _ _
PE
Ground
Fault
PTC
Additional Inputs for 193-EIOGP-42-_ _ _
+
t
