624 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Appendix A Specifications
Inductive Load Rating (p.f. = 0.4)
(L/R = 7 ms)
2 A, 250V AC
2 A, 30V DC
Short Circuit Current Rating 1,000 A
Recommended Control Circuit Fuse
KTK-R-6
(6 A, 600 V)
Rated Number of Operations
Relay 0, Relay 1, and Relay 2:
W/100-C09…100-C43
W/100-C60…100-C85
W/NEMA Size 0…2
W/NEMA Size 3
5,000,000
2,500,000
1,000,000
300,000
Table 575 - Input Ratings (Control Module and Expansion Digital Module)
Terminals
Input 0:
Input 1:
Input 2:
Input 3:
Input 4:
Input 5:
IN0
IN1
IN2
IN3
IN4
IN5
Supply Voltage 24V DC 120V AC 240V AC
Type of Inputs Current Sinking
On-State Voltage 11V DC 74V AC 159V AC
On-State Current (turn-on) 2 mA 5 mA 5 mA
Off-State Voltage 5V DC 20V AC 40V AC
Off-State Current 1.5 mA 2.5 mA 2.5 mA
Transition Voltage 5...11V DC 20…74V AC 40…159V AC
Transition Current 1.5...2.0 mA 2.5…5 mA 2.5…5 mA
Table 576 - Analog I/O Ratings (Expansion Analog Module)
Module
Bus to In/Out isolation 1000V AC = 1415V DC (1 min.)
Group Isolation (In/Out) 1000V AC = 1415V DC (1 min.)
Channel to channel isolation None
Max. current draw 85 mA at 24V
Max. Surge Current at Power-Up 0.5 A @ 24V DC for 1 ms
Input Channels
Input ranges
Current: 0…20 mA, 4…20 mA
Voltage: 0…10V, 1…5V, 0…5V
RTD: 100 , 200 , 500 and 1000 PT385 and Pt3916, 100 Ni618 and Ni672, 10
Cu 426, 604 NiFe 518
Resistance: 0-150 , 0-750 , 0-3000 , 0-6000
Input Impedance Tolerances
Current Impedance: 249 ± 1.0%
Voltage Impedance:
10M at 10V
in
4M at 5V
in
680k at 1V
in
Input resolution 12 bits
Table 574 - Output Relay Ratings (Control Module and Expansion Digital Module)
