Allen-Bradley E300 User Manual

718 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Appendix D EtherNet/IP Information
47 Fault47
48 Fault48
49 TestTrip Test trip caused by holding the Test/Rest button for 2 seconds
50 PTCTrip PTC input indicates that the motor stator windings overheated
51 DLXTrip DeviceLogix defined trip was generated
52 OperStationTrip The Stop button the Operator Station was pressed
53 RemoteTrip Remote trip command detected
54 BlockedStartTrip Maximum starts per hour exceeded
55 Trip55 Hardware configuration fault. Check for shorts on input terminal
56 ConfigTrip Invalid parameter config. See parameters 38-39 for details
57 Trip57
58 DLXFBTimeoutTrip DeviceLogix Feedback Timeout Trip was detected
59 Trip59
60 Trip60
61 Trip61
62 NVSTrip NonVolatile Storage memory problem detected
63 Trip63
64 Trip64
65 InAnMod1Ch00Trip Input Channel 00 on Analog Module 1 exceeded its Trip Level
66 InAnMod1Ch01Trip Input Channel 01 on Analog Module 1 exceeded its Trip Level
67 InAnMod1Ch02Trip Input Channel 02 on Analog Module 1 exceeded its Trip Level
68 InAnMod2Ch00Trip Input Channel 00 on Analog Module 2 exceeded its Trip Level
69 InAnMod2Ch01Trip Input Channel 01 on Analog Module 2 exceeded its Trip Level
70 InAnMod2Ch02Trip Input Channel 02 on Analog Module 2 exceeded its Trip Level
71 InAnMod3Ch00Trip Input Channel 00 on Analog Module 3 exceeded its Trip Level
72 InAnMod3Ch01Trip Input Channel 01 on Analog Module 3 exceeded its Trip Level
73 InAnMod3Ch02Trip Input Channel 02 on Analog Module 3 exceeded its Trip Level
74 InAnMod4Ch00Trip Input Channel 00 on Analog Module 4 exceeded its Trip Level
75 InAnMod4Ch01Trip Input Channel 01 on Analog Module 4 exceeded its Trip Level
76 InAnMod4Ch02Trip Input Channel 02 on Analog Module 4 exceeded its Trip Level
77 Trip77
78 Trip78
79 Trip79
80 Trip80
81 DigitalMod1Trip Digital Expansion Module 1 is not operating properly
82 DigitalMod2Trip Digital Expansion Module 2 is not operating properly
83 DigitalMod3Trip Digital Expansion Module 3 is not operating properly
84 DigitalMod4Trip Digital Expansion Module 4 is not operating properly
85 AnalogMod1Trip Analog Expansion Module 1 is not operating properly
86 AnalogMod2Trip Analog Expansion Module 2 is not operating properly
87 AnalogMod3Trip Analog Expansion Module 3 is not operating properly
88 AnalogMod4Trip Analog Expansion Module 4 is not operating properly
89 Trip89
90 CtlModMismatch Control Module installed does not match the expected type
91 SenseModMismatch Sensing Module installed does not match the expected type
92 CommModMismatch Comms Module installed does not match the expected type
93 OperStatMismatch Operator Station installed does not match expected type
94 DigModMismatch Digital Module installed does not match the expected type
95 AnModMismatch Analog Module installed does not match the expected type
96 Trip96
Fault Code Fault Text Help Text
