720 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Appendix D EtherNet/IP Information
The following common services are implemented for the DPI Warning Object.
Table 654 - DPI Warning Object Common Services
The table below lists Warning Codes, Warning Text, and Warning Help Strings.
Table 655 - Warning Codes, Warning Text, and Warning Help Strings
Service Code
Implemented for:
Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 Yes No Set_Attribute_Single
Warning
Code
Warning Text Warning Help Text
0 No Warning No Warning Conditions Detected
1 OverloadWarning Approaching a motor current overload condition
2Warning2
3 Ground Fault Power conductor or motor winding is shorting to ground
4Warning4
5 JamWarning Motor current has exceed the programmed jam warning level
6 UnderloadWarning Motor current has fallen below normal operating levels
7 Current ImbalWarn Phase to phase current imbalance detected
8 L1UnderCurrWarn L1Current was below L1 Undercurrent Warning Level
9 L2UnderCurrWarn L2Current was below L2 Undercurrent Warning Level
10 L3UnderCurrWarn L3Current was below L3 Undercurrent Warning Level
11 L1OverCurrenWarn L1 Current was over L1 Overcurrent Warning Level
12 L2OverCurrenWarn L2 Current was over L2 Overcurrent Warning Level
13 L3OverCurrenWarn L3 Current was over L3 Overcurrent Warning Level
14 L1LineLossWarn L1 Current Lost for longer than the L1 Loss Trip Delay
15 L2LineLossWarn L2 Current Lost for longer than the L2 Loss Trip Delay
16 L3LineLossWarn L3 Current Lost for longer than the L3 Loss Trip Delay
17 UnderVoltageWarn Line to Line Under-Voltage condition detected
18 OvervoltageWarn Line to Line Over-Voltage condition detected
19 VoltageUnbalWarn Phase to phase voltage imbalance detected
20 PhaseRotationWrn The unit detects the supply voltage phases are rotated
21 UnderFreqWarning Line voltage frequency is below the warning level
22 OverFreqWarning Line voltage frequency has exceeded warning level
23 Warning23
24 Warning24
25 Warning25
26 Warning26
27 Warning27
28 Warning28
29 Warning29
30 Warning30
31 Warning31
32 Warning32
33 UnderKWWarning Total Real Power (kW) is below warning level
34 OverKWWarning Total Real Power (kW) has exceeded warning level
35 UnderKVARConWarn Under Reactive Power Consumed (+kVAR) condition detected
36 OverKVARConWarn Over Reactive Power Consumed (+kVAR) condition detected
37 UnderKVARGenWarn Under Reactive Power Generated (-kVAR) condition detected
