13.6
Checking start speed increase
(choke), adjusting if necessary
Checking start speed increase
•
Remove left battery cover.
•
Set speed increase to limit stop (stage 2).
e Caution:
Screw (2) is sealed with lacquer and must not be
turned.
L Note:
Stop face (1) must be in contact with screw (2) and
the cable must have no play; if this is not the case,
play at the cable must be adjusted.
•
Check stop face (1).
Adjusting start speed increase
•
Set speed increase to limit stop (stage 2).
•
Loosen locknut (3).
•
Press lever with stop face (1) against screw (2).
•
Turn adjusting screw (4) until there is no play at
the cable.
•
Retighten locknut (3).
LT130030
4
1
3
2
