21.8
Installing clutch housing
•
Coat tapers in clutch housing with
Optimoly MP 3 or similar.
•
Fit thrust washer (1) on the clutch housing.
•
Using retaining device, fit clutch housing in the
correct position.
•
Install thrust ring (4) with new O-ring (3).
•
Screw on hexagon nut (5).
e Caution:
The hexagon nut must be renewed every time it is
removed.
X Tightening torques:
1. Tighten hexagon nut .............................. 140 Nm
2.
Loosen hexagon nut again
3. Tighten hexagon nut ................................ 50 Nm
4.
Tightening angle .......................................... 50 °
LT210050
3
1
5
4
2
