46.21
Removing and
installing sea
t lock
1.
Saucer-head screw
2.
Phillips-head scr
ew
3.
Stop
nut
Removing and
installing handl
e
•
Lever out spri
ng using
screwdriver,
remove
spring seat.
•
Detach handle.
•
Remove spring with second spring
seat.
•
Install in the reverse order
of removal.
L
Note:
Grease the pivot po
int a little before i
nstalling han-
dle. Spring seats must eng
age in the gro
oves.
LT510040
2
1
3
322
324
