61.7
Removing and installing battery
e
Caution:
Switch off ignition, disconnect and insulate ground
lead!
•
Remove Motronic control unit.
•
[ABS I]
Remove ABS
control unit.
•
Disconnect positiv
e lead.
•
Detach vent hose (1).
•
Install in the reverse order
of removal.
L
Note:
First
connect posi
tive pole,
followed by n
egative
pole. Coat battery terminals with acid-free grease.
Fit battery vent hose without kinks.
LT610030
1
342
