61.5
Removing and installing Motron
ic
control unit
e
Caution:
Switch off ignition, disconnect and insula
te earth
(ground
) lead!
•
Open dualseat.
•
Press
catch (1
) for mu
lti-pin
plug an
d detac
h
plug.
•
Loosen scre
ws (2) and remove c
ontrol unit
.
X
Tighteni
ng torque:
Motroni
c control
unit
........
..........
..........
.......
...
5 Nm
LT610010
2
1
340
