11.15
Stripping down and re-assembling
intermediate flange
Removing the driver bearing
•
Bearing plate (1)
•
Cup spring (2)
•
Pull out ball bearing (3) with counter-support,
BMW No. 00 8 572, and internal puller 21/2,
BMW No. 00 8 571.
•
Seeger circlip (4)
Installing driver bearing
•
Heat the intermediate flange at the bearing seat
to 120 °C.
•
Press the ball bearing in as far as the Seeger cir-
clip.
4
3
2
1
j
120
LT110120
•
Insert the cup spring with the larger diameter fac-
ing the bearing.
•
Install the bearing plate with the large cutout fac-
ing upwards.
•
The retaining screws must be clean and free
from grease; insert them with Loctite 243.
X Tightening torque:
Bearing plate.................................................. 9 Nm
LT110130
