46.18
Checking frame with gauge
•
Remove fairing.
•
Support motor cycle with lifting gear,
BMWNo.001510.
•
Remove telescopic fork.
•
Outer bearing race at top and bottom remain in
steering head.
•
[RS] Remove left and right footrest plate.
•
Release frame securing screw at gearbox.
L Note:
After releasing the frame securing screw at the gear-
box, check that the screws can be screwed in again
easily.
If this is not possible, the frame is in all probability
distorted.
•
Fit adapter, BMW No. 46 5 606, instead of se-
curing screws.
•
Screw measuring discs, BMW No. 46 5 603, at
the same level on the adapter.
•
Connect frame test gauge (1),
BMWNo.465600,at bottom of steering head
and clamp together frame and gauge with spin-
dle (2), BMW No. 46 5 604, and crank (3).
LT460230
2
3
46 5 600
1
