46.9
Removing an
d installing wi
ndshield
•
Release securi
ng screws (1) on
left and right and
detach screen.
Removing an
d installing wi
ndshield
compl
ete wit
h motor
•
Remove inner cover.
•
Release securing sc
rews (2).
•
Detach water ducts (3) at the top nipple.
•
Disconnect electrical p
lug connection.
•
Remove wi
ndshield w
ith motor.
•
Install in the reverse order
of removal.
L
Note:
Ensure the water ducts are fitted in the correct
positi
on.
LT460070
2
1
3
1
2
3
310
312
