11.31
Removing output shaft
Removing oil sump
•
After removing the screws, loosen the seal with
light blows of a plastic-faced hammer.
Removing oil filter
•
Unscrew oil filter (1) with the oil filter wrench,
BMW No. 11 4 650.
Removing lower section of crankcase
•
Take out retaining screws and screws (3) holding
the output shaft.
•
With light blows of a plastic-faced hammer, loos-
en the gasket and take off the lower section of
the housing. Note presence of O-rings.
•
Carefully lift out the output shaft; the needle roller
bearing and circlip are loose on the shaft.
LT110440
2
3
1
Removing and installing oil level sight glass
•
Pierce the plastic disc with a large screwdriver
and lever out the oil level sight glass.
•
Oil the sealing face of the oil level sight glass
lightly and drive it in with a drift,
BMWNo.005550.
