Checking fuel pump pressure
•
Connect test pressure gauge,
BMW
No.
16
1
5
00
, on the delivery side.
•
Run engine at idle
speed.
Fuel pressure:
Nomi
nal valu
e
......
........
.......
.......
2.5 bar
(36.
26 psi)
•
If the fu
el pressure
is lower, che
ck pump
, fuel fil-
ter and line.
LT160050
16
1
500
140
142
