Locations and connections, ABS
wiring loom
L
Note:
All ABS plug connecti
ons are blue.
1.
[ABS I]
Multi-pin p
lug, ABS control unit
2.
[
ABS I]
Plug connection, front pressure
modulator
3.
[ABS I]
Plug connection, rear pressur
e
modulator
4.
Plug connection, front sensor
5.
Plug connection, rear sensor
L
Note:
[ABS II]
See Group 34.
LT610050
5
1
2
3
4
344
346
