13.13
Removing an
d installing in
jectors
•
Release wire retainer (1) and detach plug (2).
•
Release clip (3) at the injector
and pull it out.
•
Install in the reverse order
of removal.
L
Note:
Ensure that the O-ring on the injector
is in good con-
dition!
Removing and i
nstalling intake
stub
pipe
X
Tig
htening torque:
Intake s
tub pipe
........
.......
.......
..........
........
.....
9 Nm
LT130120
3
2
1
LT130130
130
132
