00.9
46 Frame
Frame to engine 45
Fairing support bracket to frame 9
Suspension strut to frame/rear wheel drive 51
Handlebar to clamping block 22
Clamping screws of fork bridge 15
Locking tube 65
Hexagon nut 65
Centre stand to bearing block 41
Side stand to bearing block 41
Footrest plate 15
Brake line to handbrake cylinder 11
Brake line to distributor 11
51 Equipment
Handlebar clamping blocks 22
Shear bolts
to shear point (~ 20 )
61 General electrical equipment
Central earth (ground) 9
Motronic control unit 5
Model K 1100 LT K 1100 RS
Connection Nm
