11.43
Installing camshafts
L Note:
Note correct identification of camshafts.
Inlet side : three grooves after thrust bearing
Exhaust side: two grooves after thrust bearing
•
The camshaft bearing caps are also marked.
Inlet side: odd numbers
Exhaust side: even numbers
•
The numbers increase from the front (timing end)
to the rear.
•
Oil the camshafts at their bearing points.
•
Tighten the bearing caps uniformly, working from
the inside outwards.
•
Install the thrust bearing (timing end) with chain
guide last of all.
X Tightening torque:
Bearing cap.................................................... 9 Nm
