34.24
Removing and installing rear brake
disc
•
Remove brake caliper.
•
Remove rear wheel.
•
Remove brake disc.
L Note:
Mark installation position of the brake disc so that
the vertical runout of the pulse wheel is not
changed.
•
Install in the reverse order of removal.
L Note:
Screw in retaining screws with Loctite 270.
Check ABS sensor spacing, if necessary adjust with
spacer plates.
X Tightening torque:
Brake disc carrier......................................... 21 Nm
e Caution:
ABS - The vertical runout must be determined if the
brake disc and therefore also the pulse wheel are re-
placed.
LT340150
