11.49
Installing cylinder head cover
•
Insert reamed bolt (arrow), BMW No. 11 1 980,
into inner front hole.
•
Press centering pin, BMW No. 00 5 500, into
mount under the third camshaft bearing.
•
Install the cylinder head cover gasket with the
half-moon cutouts first. The marks at the front
and rear of the gasket and the cylinder head cov-
er must coincide.
•
Oil the gasket and half-moons lightly.
•
Press in the half-moon on the gearbox side first.
•
Apply a small amount of 3-Bond 1209 to the joint
area of the cylinder head and timing case cover.
•
Attach the cylinder head cover with gasket.
•
Insert all retaining screws as far as possible.
•
Tighten the retaining screws in a crosswise pat-
tern, working from the inside outwards.
X Tightening torque:
Cylinder head cover ....................................... 8 Nm
•
Take out the reamed and centering screw and in-
sert the remaining retaining screws.
LT110720
11 1 990
LT110730
