34.7
Assembling front brake caliper
•
Coat new se
aling rings
(3,4) with br
ake fluid and
install.
•
Coat brake ca
liper pis
tons (2) with brak
e fluid
and inse
rt.
e
Caution:
Do not tilt the
brake pistons
when installing.
•
Using
piston resettin
g tool (5),
BMW
No. 34 1 500
, press
the pistons fully back.
•
Insert brake pads and
secure with retainers.
LT340280
34 1 500
5
2
4
3
1
2
3
4
264
266
