Cisco ASR 1000 Series Software Configuration Guide

DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Router# configure terminal
Step 1
Enters the controller mode of the WAN-PHY SPA. In
this example, it enters slot 1 of SIP 2.
controller wanphy interface-path-id
Example:
Router(config)# controller wanphy 2/1/0
Step 2
Passes the string of J1 bytes specified to the remote
end of WAN-PHY SPA.
wanphy flag j1 transmit string
Example:
Router(config-controller)# wanphy flag j1 transmit
passing_string_from_localend
Step 3
In this example, the string value
passing_string_from_localend is transmitted to the
remotely connected WAN-PHY SPA.
Exits Controller-configuration (config) mode and enters
global configuration mode.
exit
Example:
Router(config-controller)# exit
Step 4
Exits global-configuration (config) mode and enters
privilege-exec mode.
exit
Example:
Router(config)# exit
Step 5
This command must be executed on the remotely
connected SPA. The command output displays the
show controller wanphy <interface-path-id>
Example:
Router# show controller wanphy 2/2/0
Step 6
string of J1 byte values transmitted from the other end
of the WAN-PHY SPA to check the path.
In this example, the last line Remote J1 Byte, of the
show controller wanphy 2/2/0 command output
Example:
TenGigabitEthernet0/2/0
indicates that the string value
passing_string_from_localend has been sent from the
other end of the WAN-PHY SPA.
Example:
Mode of Operation: WAN Mode
Example:
SECTION
Example:
LOF = 0 LOS = 0 BIP(B1) = 0
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS XE
Everest 16.5
OL-14127-17 159
Configuring the Ethernet SPAs
Configuring the Flag for Path Trace
